One Audio RSQ3 Series – Reference SQ Subwoofer
£609.00
- EUR: €704
Reference grade high displacement SQ driver
New for the entry series of products, the RSQ3 is an excellent solution for your higher power sealed and ported SQ needs.
The One Audio RSq3 series of subwoofers is designed for sealed or ported SQ applications. An aluminum inductance pole sleeve along with an upper aluminum cap helps mitigate and linearize induction. An 82mm wind height 3″ diameter 4 layer round wire coil yields 32mm of Xmax for incredible bottom octave performance. Using a rigid fiber impregnated pressed long fiber kraft paper pulp cone and a specially formulated foam surround along with a single progressive conex spider for excellent linear mechanical control. As with all One Audio subs, I machine, coat, and assemble the subwoofers in house. The RSq3 motor utilizes 3 high grade ferrite magnets for its motor force and has 1500W of RMS power handling. Incredible detail and sound quality from our higher power entry level sealed/ported series.
12″ only.
Recommended enclosure size,
1.2 cf net Sealed
2.2 cf net Vented, tuned to 28Hz
Features
Thiele-Small Parameters
| RSQ3 12 | ||
|---|---|---|
| Coils | D1/D2 | |
| FS | 26.3Hz/25.8Hz | |
| RE | .93Ω/coil / 1.85Ω/coil | |
| QMS | 4.21 / 4.17 | |
| QES | 0.53/0.51 | |
| QTS | 0.47/0.45 | |
| MMS | 326.8g/339.6g | |
| Le | 1.01 mH/2.12mH | |
| SD | 490cm^2 | |
| VAS | 37.01 l / 36.78 l | |
| SPL | 83.05 1W/1m / 83.01 1W/1m | |
| BL (NA) | 13.84 / 20.57 | |
| XMAX | 32mm (One Way) |
Technical Specifications
| RSQ3 12 | ||
|---|---|---|
| Overall Diameter | 12.625″ | |
| Cutout Diameter | 11.125″ | |
| Mounting Depth | tba | |
| DriverDisplacement | 0.23 cuft |
| Weight | 19 kg |
|---|
